RADIUS Profile Configuration

Subscriber management allows the configuration of a RADIUS profile, which is mandatory if RADIUS is used for authentication or accounting.

The diagram below illustrates how the RADIUS profile is associated with the subscriber management tasks at a broader level.

Figure 1. RADIUS Profile Configuration

Configuring the RADIUS Profile

The RADIUS profile configuration involves setting up various parameters that define how the router interacts with the RADIUS server for authentication, accounting, and so on.

set access radius-profile <profile-name> accounting accounting-backup [false | true]
set access radius-profile <profile-name> accounting accounting-backup-max [1 - 4294967295]
set access radius-profile <profile-name> accounting accounting-on-off [false | true]
set access radius-profile <profile-name> accounting accounting-on-wait [false | true]
set access radius-profile <profile-name> accounting algorithm-type [DIRECT | ROUND-ROBIN]
set access radius-profile <profile-name> accounting radius-server-profile-name <radius-server-profile-name>
set access radius-profile <profile-name> accounting stop-on-reject [false | true]
set access radius-profile <profile-name> authentication algorithm-type [DIRECT | ROUND-ROBIN]
set access radius-profile <profile-name> authentication radius-server-profile-name <radius-server-profile-name>
set access radius-profile <profile-name> calling-station-id-format [NONE | MAC]
set access radius-profile <profile-name> nas-identifier <nas-identifier>
set access radius-profile <profile-name> nas-ip-address <nas-ip-address>
set access radius-profile <profile-name> nas-port-format [DEFAULT | SLOTS | PORTS]
set access radius-profile <profile-name> nas-port-type [Virtual | SDSL | ADSL-CAP | ADSL-DMT | Ethernet | xDSL | Cable | PPPoA | PPPoEoA | PPPoEoE | PPPoEoVLAN | PPPoEoQinQ | xPON]

Attribute Description

calling-station-id-format

Set the value for RADIUS attribute Calling-Station-Id (31). The default setting is NONE, meaning the attribute is not sent. If set to MAC, the client MAC address is sent as a string. Default: NONE.

nas-identifier

Set the value for the RADIUS attribute NAS-Identifier (32). Default: system hostname.

nas-ip-address

Set the value for RADIUS attribute NAS-IP-Address (4). Default: source IPv4 address.

nas-port-type

Set the value for RADIUS attribute NAS-Port-Type (61). Default: Ethernet.

nas-port-format

Set the format of the 32-bit RADIUS attribute NAS-Port (5).

Name

Bits

Values

DEFAULT

1:1:6:12:12

slot:subslot:port:vlan:vlan

SLOTS

6:2:6:12:6

slot:subslot:port:vlan:vlan

PORTS

0:1:7:12:12

slot:subslot:port:vlan:vlan

api To access the RESTCONF API that corresponds to this CLI, click here.

The following example shows a typical RADIUS profile for authentication and accounting. The RADIUS profile name is specified as 'radius-default'. NAS Identifier is set as BNG and NAS Port Type is specified as 'Ethernet'. RADIUS servers used for authentication is set 'radius-server-1' and 'radius-server-2'. RADIUS servers used for accounting is also set as 'radius-server-1' and 'radius-server-2'.

The Accounting RADIUS servers are specified as 'radius-server-1' 'radius-server-2'. For information about other options, see the table descriptions below.

supervisor@switch: cfg> show config access radius-profile radius-default
{
  "rtbrick-config:radius-profile": {
    "profile-name": "radius-default",
    "nas-identifier": "BNG",
    "nas-port-type": "Ethernet",
    "authentication": {
      "radius-server-profile-name": [
        "radius-server-1",
        "radius-server-2"
        ]
    },
    "accounting": {
      "radius-server-profile-name": [
        "radius-server-1",
        "radius-server-2"
        ],
      "stop-on-reject": "true",
      "stop-on-failure": "true",
      "accounting-on-off": "true",
      "accounting-on-wait": "true",
      "accounting-backup": "true",
      "accounting-backup-max": 86400
    }
  }
}

Configuring Authentication

The following configuration command and options set the 'radius-profile' as authentication method. It also defines the list of RADIUS servers and the algorithm for RADIUS high-availability.

Attribute Description

Attribute	Description
`-`	Without any option, the command sets authentication for the RADIUS profile.
`radius-server-profile-name`	List of multiple RADIUS servers used for authentication.
`algorithm-type`	Specifies the authentication server selection algorithm. For more information, see RADIUS Redundancy. Default: DIRECT Values: DIRECT, ROUND-ROBIN

-

Without any option, the command sets authentication for the RADIUS profile.

radius-server-profile-name

List of multiple RADIUS servers used for authentication.

algorithm-type

Specifies the authentication server selection algorithm. For more information, see RADIUS Redundancy. Default: DIRECT Values: DIRECT, ROUND-ROBIN

api To access the RESTCONF API that corresponds to this CLI, click here.

Configuring Accounting

Configuring accounting involves specifying its name and defining various parameters. The following command and options allow you to configure RADIUS accounting.

Attribute Description

Attribute	Description
`-`	Without any option, the command sets accounting for the RADIUS profile.
`radius-server-profile-name`	List of RADIUS servers used for accounting.
`algorithm-type`	Specifies the accounting server selection algorithm. For more information, see RADIUS Redundancy. Default: DIRECT, Values: DIRECT and ROUND-ROBIN.
`stop-on-failure`	If set to `true`, the accounting will stop, if there is a failure in the process after authentication was accepted. Default: False.
`stop-on-reject`	If set to `true`, when the authentication is rejected, the accounting process will stop. Default: False.
`accounting-on-off`	Enables RADIUS Accounting-On/Off messages. For more information, see RADIUS Accounting. Default: False.
`accounting-on-wait`	Waits for an `Accounting-On` response ensuring that no new subscriber is allowed until the accounting process has been initiated. Default: False.
`accounting-backup`	Enables backup for accounting (optional). RADIUS accounting requests are often used for billing and, therefore should be able to store and retry over a longer period (commonly, up to 24 hours or more). Default: False.
`accounting-backup-max`	If enabled, this option defines maximum backup accounting hold time, in seconds. Default: 3600, Range: 1 - 4294967295.

-

Without any option, the command sets accounting for the RADIUS profile.

radius-server-profile-name

List of RADIUS servers used for accounting.

algorithm-type

Specifies the accounting server selection algorithm. For more information, see RADIUS Redundancy. Default: DIRECT, Values: DIRECT and ROUND-ROBIN.

stop-on-failure

If set to true, the accounting will stop, if there is a failure in the process after authentication was accepted. Default: False.

stop-on-reject

If set to true, when the authentication is rejected, the accounting process will stop. Default: False.

accounting-on-off

Enables RADIUS Accounting-On/Off messages. For more information, see RADIUS Accounting. Default: False.

accounting-on-wait

Waits for an Accounting-On response ensuring that no new subscriber is allowed until the accounting process has been initiated. Default: False.

accounting-backup

Enables backup for accounting (optional). RADIUS accounting requests are often used for billing and, therefore should be able to store and retry over a longer period (commonly, up to 24 hours or more). Default: False.

accounting-backup-max

If enabled, this option defines maximum backup accounting hold time, in seconds. Default: 3600, Range: 1 - 4294967295.

api To access the RESTCONF API that corresponds to this CLI, click here.
